PowerJacket Features

Displays the patient gender, name, age, DOB, and MRN.

Age displays in the following format:

• If less than 3 months, age displays in days.
• If between 3 months and 3 years, age displays in months.
• If between 3 years and 18 years, age displays in years and months using the form aY bM (where a is years, b is months).
• If older than 18 years, age displays in years.

Provides access to grouping studies, study comparison, viewing thumbnails, Synapse Chat, and refreshing the PowerJacket Studylist. See screen capture above.

See Synapse Chat Overview.

Use the Resize Font icon located in the top right of the PowerJacket page to adjust the font size of the PowerJacket grid, as well as the lower panes where Notes, Reports, and Study information displays. Use this feature to make the font smaller or larger without affecting your default settings.

See Setting PowerJacket Font Sizes.

Provides the ability to reorder studies, grouping the more relevant studies together at the top of the list.

See Grouping Studies for specifics on grouping options.

Use to compare the current study to another study or to multiple studies.

See Manually Selecting Comparisons in PowerJacket.

Use to turn off study comparison.

See Manually Selecting Comparisons in PowerJacket.

Use to display the thumbnails of each study in the list.

See Displaying and Rearranging Thumbnails in PowerJacket.

If more thumbnails exist than there are columns to display them, an indicator displays on the right side of the thumbnails preview indicating that additional series are available. Open the study to view additional series.

See Displaying Thumbnails in PowerJacket.

Displays a check box for the Series Management > Delete Selected Series option.

See Deleting Selected Series.

Click Refresh to view the most current information.

Synapse Chat provides the ability for Synapse users to communicate with one another within the Synapse application. Click the Synapse Chat icon from your preferred location in the Worklist, PowerJacket, or Viewer.

See Synapse Chat Overview.

The Snapshot icon indicates that the study contains saved display states. Right-click to:

• Display the context menu that lists the display states.
• Invoke the Snapshot context menu. Options include the ability to edit a Snapshot name or delete the Snapshot from the study.

Note that auto-saved Snapshots cannot be deleted.

The Reports icon displays when the study includes at least one report.

This Lock icon displays for the studies in Preliminary or Complete status that are locked by the logged in user. It provides a quick, visual means of determining which of the locked studies are yours. Hover over the icon to display the user information for all users who currently have the study locked.

PowerJacket displays the Lock (concurrency) icon to indicate that other users with dictation privileges currently have the study open. Hover over the icon to view the user or users who have the study currently open and how long the study has been open.

See Viewing Study Lock in PowerJacket.

Displays in the Lock column when the study is being dictated by another user.

• Hover over the icon to display the user information for all users who currently have the study locked.

Displays in the Lock column when the study is being dictated by you.

• Hover over the icon to display the user information for all users who currently have the study locked.

The Documents icon displays when the study includes at least one document.

See Scanning Documents.

The Notes icon displays when the study includes at least one note.

PowerJacket includes a large number of column options from which to select. Customize your PowerJacket columns to best meet your needs. See Modifying Columns.

For example, use the Dictated By column in conjunction with the Status column to quickly identify who signed a report and its current status.

For specific information about usage of the Dictated By column, see Study Status Handling for PowerScribe Users

Hover over a name in either the Referring Physician column or the Requesting Physician column to display the physician's phone number.

Use your mouse to select additional studies to compare or deactivate a comparison.

PowerJacket displays patient studies.

See Using PowerJacket Context Menu.

The Information pane header displays a study icon, the procedure description, the study date and time, the study count, and study navigation arrows, if applicable.

See Viewing Panes and Header Information.

PowerJacket displays documents and image files associated with the study you have open. Open any of the following file types directly in the Information pane.

See Viewing Documents in PowerJacket.

View, add, edit, and delete notes associated with the selected study.

See Managing Notes.

View reports associated with the selected study.

See Viewing Reports in PowerJacket.

If this feature is configured for your site, a Synapse 3D table of contents displays series, Snapshots, movies, screen captures, and reports.

See Using Synapse 3D in PowerJacket.

The Bookmarks icon displays in the Bookmarks column to indicate that a study includes one or more bookmarks.

The AI Submitted icon displays when the study with AI findings is queued along with other AI findings; until the findings are processed, they are not yet available.

The AI in Progress icon displays while the AI engine processes the AI findings. Once the study is processed and the Worklist refreshes, the appropriate icon displays.

The AI Scan Complete icon displays when the AI scan is fully processed.

The AI Failure / Rejected icon displays when the third-party AI vendor communicates a failed or rejected status to Synapse.

The Is CV Migrated icon displays in the Is CV Migrated column when Synapse migrates the study from Synapse CV. When you open a CV migrated study, the Viewer does not display the CRA icon , and the CRA application does not automatically open.

The Caching Status icon displays when the study is cached.
